The B-Series 32-inch basic grill head, built to drop into a masonry or non-combustible island. 4 stainless tube burners put 56,000 BTU under 690 square inches of 8 mm stainless grate, under a double-lined hood.
- 4 x 14,000 BTU stainless tube burners — 56,000 BTU under 690 square inches of cooking surface.
- Double-lined hood — holds heat for roasting and indirect work instead of bleeding it out the top.
- Heat zone dividers — run a searing side and a holding side on one grill without the two bleeding together.
- Flare Control vaporizers — drippings turn to smoke above the burners rather than pooling and flaring.
- 8 mm (5/16″) stainless grids, stainless warming rack and a slide-out drip tray that empties without dismantling anything.
- Ships with the opposite-gas conversion kit in the box.
Specifications
| Fuel | Natural Gas |
| Edition | Basic |
| Main burners | 4 x 14,000 BTU stainless tube |
| Total output | 56,000 BTU |
| Cooking surface | 690 sq in |
| Cooking grids | 8 mm (5/16") stainless steel |
| Construction | 304 stainless steel |
| Rotisserie burner | Not fitted on this edition |
| Rotisserie kit | Optional — BSAMR32 |
| Control panel / interior lights | Not fitted on this edition |
| Cut-out dimensions | 8-1/2"H x 31"W x 20-1/2"D |
| Ignition | Flame Thrower |
| Thermometer | Built-in |
| Warranty | Limited lifetime rust-through on stainless; 5 yr / 1 yr on listed parts |
What's Included
- B-Series 32-inch basic grill head, natural gas — BSB324NLN
- 8 mm stainless cooking grids, stainless warming rack, Flare Control vaporizers, heat zone dividers
- Slide-out drip tray and built-in thermometer
- Opposite-gas conversion kit
Options On This Page
- Weather cover (BSACV34S, +$84) — black, sized for the grill head alone.
- Low-pressure hose & regulator (B069756, +$27) — needed only on a propane unit run from a 20 lb tank.
Installing into a combustible island? An insulated jacket is required — ask us for BSASL32 ($459). It is not needed for masonry or metal-framed islands.
Documentation
Warranty
Broilmaster's B-Series stainless warranty runs a limited lifetime against rust-through on the stainless housing, cooking grids, cart, cast stainless burners, drip pans, warming rack and built-in components (one-time replacement); 5 years against rust-through on V-grates, flame tamers, heat zone partitions and infrared burners; and 1 year on valves, knobs, ignitors, hoses and fittings. Original purchaser only, non-transferable.
Specifications
| Version | Without Cover / Without Hose/Reg |
|---|---|
| Grill head width (in) | 32 |
| Burners | 4 |
| Version | Without Cover / Add For LP Conversion +$27 |
|---|---|
| Grill head width (in) | 32 |
| Burners | 4 |
| Version | With Cover +$84 / Without Hose/Reg |
|---|---|
| Grill head width (in) | 32 |
| Burners | 4 |
| Version | With Cover +$84 / Add For LP Conversion +$27 |
|---|---|
| Grill head width (in) | 32 |
| Burners | 4 |
Specifications and manuals
Compare similar items
Shipping & returns
Shipping & delivery
- Delivery options and pricing by ZIP at checkout.
- Gas, electric and wood installation available
- Collect from our showroom at 70-01 Astoria Blvd N, East Elmhurst, NY 11370
Returns
- Call us to arrange a return - we will talk you through the manufacturer's terms for your unit
- Inspect your delivery before signing, and tell us the same day if anything arrived damaged
Questions? (718) 204-1166
